Brand/ Manufacturer:
SIEMENSManufacturer Part Number:
6ES7132-4BB00-0AA0Additional Information:
ELECTRON MODULESCondition:
Brand New Factory Sealed - OriginalAvailability:
1Warranty:
12 MonthsEstimated Weight:
1 kgCountry of Origin:
GermanyHS Code:
8538900000Shipping:
Worldwide by DHL /Fedex /TNT / UPSProduct Detail
|
Specification |
Value |
|
Supply Voltage |
L+ (24 V DC from power module) |
|
Reverse Voltage Protection |
Yes (when using the same load voltage as on the power module) |
|
Reverse Polarity Protection |
Yes |
|
Input Current |
From Load Voltage L+ (without load): 5 mA per channel |
|
Power Loss |
0.4 W (typical) |
|
Address Area |
With packing: 2 bit |
|
Number of Digital Outputs |
2 |
|
Short-Circuit Protection |
Response threshold: 1.5 A (typical) |
|
Limitation of Inductive Shutdown Voltage |
-55 to -60 V |
|
Controlling a Digital Input |
Yes |
|
Switching Capacity (Lamp Load) |
Max 2.5 W |
|
Load Resistance Range |
Lower limit: 48 Ω |
|
Output Voltage (for Signal "1") |
Min L+ (-1 V) |
